ERW(Electric Resistance Weld) Tube Mill Pipe Transfer Conveyor and Run Out Table

1. 4. Technical Specifications (Example)

   Item	Specification
   Conveyor Length	6–12 meters
   Roller Diameter	89–159 mm
   Motor Power	2.2–5.5 kW
   Conveyor Speed	10–30 m/min adjustable
   Applicable Pipe Diameter	Ø20–Ø168 mm
   Load Capacity	≤2000 kg



   5. Operating Instructions

   1. Check the motor, reducer, and rollers before starting.

   2. Turn on the power and press the “Start” button to activate the conveyor system.

   3. Ensure pipes are centered and move smoothly into the system.

   4. After discharging, press “Stop” to shut down the equipment.

   6. Maintenance

   • Regularly lubricate bearings and transmission parts

   • Check the chain or belt tension periodically

   • Clean the roller surfaces to prevent debris buildup

   • Inspect the motor and gearbox monthly to ensure proper function
