COIL CAR

1. 3. Technical Parameters (Example)

   Item	Parameter Example
   Load Capacity	5~150 tons (customizable)
   Travel Speed	0~20 m/min (adjustable)
   Power Supply	Battery/Conductor Rail/Cable Reel
   Control Method	Manual + Remote + Auto
   Minimum Turning Radius	Depending on vehicle size
   Working Temperature	-20°C ~ +50°C
   Surface Treatment	Sandblasting + Anti-rust Paint



   4. Working Principle

   The drive system propels the wheels to move forward or backward, enabling the steel coil to be transferred between production processes. It can be controlled via remote or central control system, with accurate positioning based on travel setup. Battery-powered versions may include auto-charging features.

   5. Application Scenarios

   • Transfer between coil storage and production lines

   • Coil feeding system in pipe mills

   • Pre- and post-heat treatment transport

   • Material handling in automated warehouse systems

   • •
     •






   6. Operating Instructions

   1. Pre-operation check: power status, wheel condition, obstacle clearance

   2. Power on control unit: operate via panel or remote controller for start, stop, speed adjustment, and direction change

   3. Position coil centered in the V-frame during loading

   4. Do not overload or allow personnel on board during movement

   5. Cut off power or return to charging station after use

   7. Maintenance

   • Weekly inspection of motor, wheel axle, and fasteners

   • Regular lubrication of transmission parts

   • For battery-powered units, check charge level and terminal corrosion regularly

   • Keep the control box dustproof and moisture-proof

   • Periodically calibrate limit switches

   8. Safety Instructions

   • Operators must receive proper training

   • Overloading or high-speed operation on inclines is strictly prohibited

   • Check all safety alarm devices before operation

   • Power must be shut off immediately in case of any abnormal situation
